This post explains how the ONYX electrical system works at a system level. While individual guides cover wiring, displays, and accessories, this page focuses on how all electrical components interact.

Use this page to understand power flow, system structure, and how different electrical subsystems connect before working on wiring or installing components.

  • Start here to understand the full electrical system
  • Use this as a reference before modifying wiring
  • This page connects high-voltage and low-voltage systems

Electrical System Overview

ONYX bikes operate using two primary electrical systems that run simultaneously.

SystemVoltagePurpose
High-voltage drivetrain72V / 80VDrives the motor
Low-voltage system12VPowers electronics and accessories

These systems are connected through a DC-DC converter, which steps high voltage down to 12V.


Power Flow Through The Bike

At a system level, electrical energy moves through the ONYX platform in three main paths.

PathFlow
DrivetrainBattery → Controller → Motor
AccessoriesBattery → DC-DC → 12V system
ChargingWall AC → Charger → Battery

Each path operates independently but shares the same battery.


Core Electrical Components

Understanding the main components helps clarify how the system behaves.

ComponentFunctionNotes
BatteryStores energy72V or 80V lithium system
ControllerConverts DC to 3-phase ACControls motor behavior
MotorProduces torqueHub motor on rear wheel
DC-DC ConverterSteps voltage to 12VPowers accessories
Wiring HarnessDistributes power and signalsConnects all systems
DisplayRider interfaceShows speed and system data

High-Voltage Drivetrain

The high-voltage system is responsible for propulsion.

ElementRole
BatterySupplies high-current DC power
ControllerConverts DC into AC waveforms
MotorConverts electrical energy into motion

This system operates at high current and should not be modified without proper understanding.


12V Accessory System

The 12V system powers all low-voltage electronics.

ComponentExample
LightingHeadlight, taillight
ControlsDisplay, switches
AccessoriesUSB chargers, GPS, cameras

This system is where most rider modifications occur.


DC-DC Converter Role

The DC-DC converter connects both systems.

InputOutput
72V / 80V battery12V accessory power

Key characteristics:

  • Limited current output
  • Shared with factory systems
  • Must be respected when adding accessories

Overloading the converter can cause instability or electrical issues.


Wiring Structure

ONYX wiring is organized through harnesses that distribute both power and signal connections.

HarnessPurpose
Main harnessConnects battery, controller, and key systems
Lighting harnessProvides 12V to lights
Accessory tapsUsed for add-ons

Clean wiring and proper routing are critical for reliability.


This page explains system-level behavior. For detailed implementation, refer to:

Use this page first, then move into detailed guides.


Common Mistakes

Electrical issues are often caused by misunderstanding system limits.

  • Treating the 12V system as unlimited
  • Overloading the DC-DC converter
  • Mixing high-voltage and low-voltage wiring incorrectly
  • Skipping fuse protection

Understanding system structure prevents most problems.


Where To Start

If you are new to ONYX electrical systems:

  1. Review this system overview
  2. Read the ONYX Wiring Guide
  3. Plan accessory power requirements
  4. Add components gradually and test

This approach reduces risk and keeps the system stable.


Quick Reference

QuestionAnswer
What powers the motor?High-voltage battery through controller
What powers accessories?12V system via DC-DC converter
Where should I modify wiring?12V system only
What connects everything?Wiring harness
What converts voltage?DC-DC converter
